CPCD20

Diesel internal combustion forklift - hydrodynamic transmission - 2 T at 500 mm load centre

CPCD20

Diesel internal combustion forklift - hydrodynamic transmission - 2 T at 500 mm load centre

The CPCD20 is a 2-tonne diesel forklift designed to load, move and store pallets. Its wide-view mast, smooth steering and suspension seat make precise manoeuvring easier while improving operator comfort during routine daily handling tasks on site.

more information

	Designation	Stock / EXW price per unit excl. VAT
	CPCD20 Diesel internal combustion forklift - hydrodynamic transmission - 2 T at 500 mm load centre The configurations available for this model will appear below. If no configuration is available in stock, you can use the configurator and send us your request by email.

DESCRIPTION

TECHNICAL CHARACTERISTICS

CPCD20 – 2-tonne diesel internal combustion forklift

The NOBLELIFT FRANCE CPCD20 is a sit-on diesel internal combustion forklift with a rated capacity of 2,000 kg at a 500 mm load centre. It is intended for outdoor or mixed operations at loading bays, logistics yards, workshops and industrial sites. Its diesel engine, increased ground clearance and robust mast support material flows without dependence on an electric charging point.

Two diesel tonnes for versatile operations

The CPCD20 can manage unloading, transfer and supply operations between outdoor areas and buildings. The long wheelbase contributes to stability. The wide mast provides a clear view of the forks. Lowering cushioning limits impact when depositing the load.

Diesel engine and hydrodynamic transmission

The four-cylinder engine delivers 36.8 kW. Its displacement is 2,850 cm³ and maximum torque reaches 165 N·m at 1,600–1,800 rpm. The 60-litre fuel tank supports extended operating periods. The hydrodynamic transmission and forward-reverse controls facilitate changes of direction.

An operator compartment suited to frequent travel

The adjustable suspension seat limits vibration. FHPS steering provides smooth control during manoeuvres. The integrated side shift facilitates fork alignment. The OPS system prevents lifting and travel when the operator is not seated.

Visibility in circulation areas

LED lights, the blue warning light, panoramic mirrors, the LCD screen and the horn integrated into the rear handle improve visibility and operating information.

Engine access designed for inspections

The gas-spring-assisted bonnet opens to provide access to the engine and main components. The air-filtration system limits dust ingress. Fluid levels, forks, mast, chains, tyres and lighting equipment must be inspected before operation.

Main technical specifications

• Rated capacity: 2,000 kg at a 500 mm load centre.
• Operating weight: 3,500 kg.
• Wheelbase: 1,660 mm.
• Standard lift height: 3,000 mm.
• Mast height lowered / extended: 1,995 / 4,025 mm.
• Overall length: 3,698 mm.
• Overall width: 1,150 / 1,163 mm depending on configuration.
• Fork dimensions: 1,070 × 120 × 40 mm.
• Turning radius: 2,270 mm.
• Travel speed, laden / unladen: 18 / 18 km/h.
• Engine power: 36.8 kW.
• Fuel-tank capacity: 60 litres.
• Starter battery: 12 V / 80 Ah.

Professional applications

• Loading and unloading at loading bays.
• Handling on logistics yards.
• Supplying workshops from outdoor areas.
• Transferring pallets between storage and production.
• Travelling on stabilised uneven ground.
• Versatile operation on industrial sites.

Frequently asked questions

What load can the CPCD20 handle?
Its rated capacity is 2,000 kg at a 500 mm load centre.

Can it be used indoors?
Indoor operation must comply with the site’s ventilation, emission and safety requirements.

What is the fuel-tank capacity?
The fuel tank holds 60 litres.

Which mast configurations are available?
Duplex, full-free-lift Duplex and full-free-lift Triplex masts are available.

To validate the CPCD20 according to your ground conditions, loads and lift heights, contact NOBLELIFT FRANCE.

Documentation

Data sheet
