CPCD40

Diesel internal combustion forklift - 4 T at 500 mm load centre

CPCD40

Diesel internal combustion forklift - 4 T at 500 mm load centre

The CPCD40 is a 4-tonne diesel forklift designed to load, unload and move heavy loads. Its long wheelbase, reinforced mast and optimised hydraulic system support stable, precise manoeuvring during demanding professional handling operations.

more information

	Designation	Stock / EXW price per unit excl. VAT
	CPCD40 Diesel internal combustion forklift - 4 T at 500 mm load centre The configurations available for this model will appear below. If no configuration is available in stock, you can use the configurator and send us your request by email.

DESCRIPTION

TECHNICAL CHARACTERISTICS

CPCD40 – 4-tonne diesel internal combustion forklift

The NOBLELIFT FRANCE CPCD40 is a sit-on diesel internal combustion forklift with a rated capacity of 4,000 kg at a 500 mm load centre. It is designed for heavy industrial applications on yards, loading bays and production areas. Its 55.8 kW engine, 90-litre fuel tank and increased ground clearance support extended operating periods.

Four tonnes for intensive outdoor operations

The CPCD40 can move dense pallets, bulky components and raw materials between storage, production and dispatch. Its 2,100 mm wheelbase supports stability. The wide mast provides good visibility during load pick-up.

A 55.8 kW engine for heavy loads

The four-cylinder engine has a displacement of 2,970 cm³. Maximum torque reaches 320 N·m at 1,200–1,600 rpm. The fuel tank holds 90 litres. The hydrodynamic transmission and hydraulic system support intensive work cycles.

Driving and safety in industrial environments

FHPS steering and the adjustable suspension seat facilitate travel. The integrated side shift helps align the forks. The OPS system prevents lifting and travel when the operator is not seated. LED lights, the blue warning light, mirrors and the rear horn improve visibility.

Engine access and dust protection

The gas-spring-assisted bonnet provides quick access to the components. The air-filtration system limits dust ingress. Routine checks include fluid levels, forks, chains, mast, tyres and signalling systems.

Main technical specifications

• Rated capacity: 4,000 kg at a 500 mm load centre.
• Operating weight: 6,350 kg.
• Wheelbase: 2,100 mm.
• Standard lift height: 3,000 mm.
• Mast height lowered / extended: 2,250 / 4,300 mm.
• Overall length: 4,305 mm.
• Overall width: 1,480 mm.
• Fork dimensions: 1,070 × 150 × 50 mm.
• Turning radius: 2,930 mm.
• Travel speed, laden / unladen: 21 / 22 km/h.
• Engine power: 55.8 kW.
• Fuel-tank capacity: 90 litres.
• Starter battery: 12 V / 120 Ah.

Professional applications

• Handling loads weighing up to 4,000 kg.
• Loading heavy pallets on yards.
• Supplying industrial workshops.
• Moving bulky components.
• Travelling on stabilised uneven ground.
• Intensive outdoor operations.

Frequently asked questions

What capacity does the CPCD40 provide?
Its rated capacity is 4,000 kg at a 500 mm load centre.

What is the engine power?
The diesel engine delivers 55.8 kW.

How much fuel can the tank hold?
The fuel tank has a capacity of 90 litres.

Which mast configurations are available?
Duplex, full-free-lift Duplex and full-free-lift Triplex masts are available.

To configure the CPCD40 according to your loads, ground conditions and working heights, contact NOBLELIFT FRANCE.

Documentation

Data sheet
