CPCD50

Diesel internal combustion forklift - 5 T at 500 mm load centre

CPCD50

Diesel internal combustion forklift - 5 T at 500 mm load centre

The CPCD50 is a 5-tonne diesel forklift intended for loading, unloading and moving heavy loads. Its robust mast, stable chassis and tool-free engine access support efficient daily handling while simplifying routine maintenance and service tasks.

more information

	Designation	Stock / EXW price per unit excl. VAT
	CPCD50 Diesel internal combustion forklift - 5 T at 500 mm load centre The configurations available for this model will appear below. If no configuration is available in stock, you can use the configurator and send us your request by email.

DESCRIPTION

TECHNICAL CHARACTERISTICS

CPCD50 – 5-tonne diesel internal combustion forklift

The NOBLELIFT FRANCE CPCD50 is a sit-on diesel internal combustion forklift designed for handling operations up to 5,000 kg at a 500 mm load centre. Its 55.8 kW engine, 90-litre fuel tank and structure designed for heavy loads meet the requirements of high-tonnage industrial sites.

Five tonnes for the most demanding handling operations

The CPCD50 can move very heavy pallets, equipment and components on yards, loading bays and production areas. Its long wheelbase supports stability. The wide mast improves visibility during load pick-up and travel. Increased ground clearance facilitates movement on stabilised outdoor areas.

An engine designed for on-site autonomy

The four-cylinder diesel engine delivers 55.8 kW from a displacement of 2,970 cm³. Maximum torque reaches 320 N·m at 1,200–1,600 rpm. The 90-litre fuel tank supports extended operating periods. The hydrodynamic transmission facilitates changes of direction.

Comfort and precision with massive loads

The adjustable suspension seat limits vibration. FHPS steering facilitates operation. The integrated side shift allows the fork position to be adjusted. Lowering cushioning reduces impact on the load during deposit.

OPS system and lighting equipment

The OPS system prevents lifting and travel when the operator is not seated. LED lights, the blue warning light, panoramic mirrors and the rear horn improve forklift visibility. The LCD screen provides operating information to the driver.

Accessible inspections for intensive-use equipment

The gas-spring-assisted bonnet provides access to the engine. The filtration system limits dust ingress. Fluid levels, forks, mast, chains, tyres, brakes and lighting equipment must be inspected regularly.

Main technical specifications

• Rated capacity: 5,000 kg at a 500 mm load centre.
• Operating weight: 6,800 kg.
• Wheelbase: 2,100 mm.
• Standard lift height: 3,000 mm.
• Mast height lowered / extended: 2,250 / 4,300 mm.
• Overall length: 4,305 mm.
• Overall width: 1,480 / 1,490 mm depending on configuration.
• Fork dimensions: 1,070 × 150 × 50 mm.
• Turning radius: 2,930 mm.
• Travel speed, laden / unladen: 21 / 22 km/h.
• Engine power: 55.8 kW.
• Fuel-tank capacity: 90 litres.
• Starter battery: 12 V / 120 Ah.

Professional applications

• Handling loads weighing up to 5,000 kg.
• Moving very heavy industrial equipment.
• Loading materials in outdoor areas.
• Supplying production sites.
• Transferring loads between storage, workshops and dispatch.
• High-tonnage operations on logistics yards.

Frequently asked questions

What rated load can the CPCD50 lift?
The CPCD50 has a rated capacity of 5,000 kg at a 500 mm load centre.

What is the engine power?
The diesel engine delivers 55.8 kW.

What is the fuel-tank capacity?
The fuel tank holds 90 litres.

Which criteria must be checked before configuration?
Load weight, load centre, lift height, residual capacity, attachments and ground conditions must be assessed.

To size the CPCD50 according to your high-tonnage loads and site constraints, contact NOBLELIFT FRANCE.

Documentation

Data sheet
